Ultrasonic Frozen Cheese Cutting Machine

For dicing or slicing bread and cakes.

Equipped with material rotating device.

The full set of action is driven by the Servo Motor.

Machine Size: L3.5M x W0.9M (divided into 2 sections).

Cut size: 600mm*600mm

Cutting speed: 60 times/minute

1 Smooth cut, ultrasonic knife used, no sticky, no crumbs;

2 Various cutting styles, cutting into pieces, diamonds, triangles and circles ;

3 Different products can be cut, cakes, bread, and pizza and so on;

4 With a good interface, easy for operation;

5 Orders available for any different products.

Ultrasonic Components

1.Stackable, ultrasonic power supplies and panel mount generator kits

2.Rigid mount ultrasonic boosters for improved stack stability

3.Wash-down duty, air-cooled converters (stainless steel body also available)

4.Food industry approved titanium blade,slitting and knife horns

Typical ultrasonic food cutting components include four major elements: a power supply, a converter, a booster and a cutting horn, as explained below.

1.Power supply

The ultrasonic power supply, also referred to as a generator, is an electronic device that takes standard 50/60Hz AC line voltage and converts it to high frequency electrical energy.

2.Converter

The ultrasonic converter is a sealed electro/mechanical device that receives the 20kHz electrical energy from the power supply and converts this electrical energy to high frequency mechanical vibrations using PZT(piezoelectric) ceramic discs that expand and contract within the converter housing.

3.Booster

The booster is a machined metal mechanical amplifier that will either raise or lower the amplitude of the horn's mechanical motion depending on the configuration of the masses machined at each end.

4.Cutting horn

The cutting horn, also referred to as a knife or a blade horn, is the component that comes into contact with the product and does the actual cutting. This horn is machined from titanium, has excellent acoustic properties, good surface hardness and superior fatigue value.

Our ultrasonic components and horns are designed for continuous operation under the most demanding production environments. Welcome customers to cooperate with us for a brilliant future!

Applications:

Frozen cakes and pies

Frozen fish

Snack and health bars

Fresh/frozen prepared meats

Dough or baked cookies

Soft and hard cheeses

Fresh/frozen vegetables

Candy and confections

Ice cream bars
