WANLI Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine Benefit:

1. High cutting precision, good cutting surface finish, accurate edge cutting, no deformation, no stick to the knife, fast speed, no pollution.

2. Reasonable design, simple structure, easy to use, easy to be applied to automatic production.Digital power supply, automatic frequency tracking and adjustable efficiency, can work continuously for 24 hours.

Objective:

Ultrasonic Cutting Triangle Cake Machine to solve the sticky knife problem in cutting soft and elastic food such as cake, bread, cheese, candy, chocolate, biscuit, pizza etc.An ultrasonic food cutting blades device is provided.

WANLI Ultrasonic Cutting Triangle Cake Machine

20250730115134

Ultrasonic triangle bread cutting equipment. Sonic chase cutting food cutting line is transformed from a variety of customized in-line food cutting models aggregated to become the new in-line ultrasonic food cutting processing equipment. The equipment has the characteristics of assembly line operation, multiple slicing mode, longitudinal knife slitting, horizontal knife slicing or cutting, in addition to the waste rejection system to automatically remove the food edge waste from the conveyor, food production efficiency and food production quality.Ultrasonic cutting knives are made of titanium, a completely inert material approved by the food industry. Titanium has good fatigue strength, surface hardness and excellent acoustic properties.

WANLI Ultrasonic Cutting Triangle Cake Machine

What is the difference between Wanli ultrasonic cutting machine and traditional ultrasonic cutting machine?

–Ultrasonic cutting machine is a special ultrasonic equipment for cutting, is one of the important categories of ultrasonic applications.

–The principle is completely different from the traditional cutting. Ultrasonic cutting machine uses the energy of ultrasonic waves to melt the local heating of the material being cut, so as to achieve the purpose of cutting the material.

–Ultrasonic cutting machine features, does not require a sharp knife edge, does not require a lot of pressure, will not be chipped and broken on the cutting material.

–Cutting baldes in doing ultrasonic vibration, friction resistance is particularly small, the material to be cut is not easy to stick to the blade.

Cutting Mode

微信图片 20250813101815 1

Machine Dimensions(L*W*H)

Cutting Example

t01a4ebefec922d4bb5

Applicable Industries

Sandwich Cake

Sandwich Bread

Features and Parameters

Main Features

  • Efficient cutting: Ultrasonic Sandwich Cake Bread Cutting Equipment cuts with high-frequency vibration, which is much faster than traditional manual cutting methods, dramatically improving production efficiency.
  • Maintaining the nutrition of ingredients: Ultrasonic Sandwich Cake Bread Cutting Equipment can reduce the loss of nutrients during the cutting process, ensuring that the nutritional value of sandwich bread is maintained.
  • Multi-functional application: In addition to sandwich bread, this cutter is also suitable for cutting other food products, such as cheese, cake, pizza, etc., with a wide range of applications.

Basic Parameters

  • Model:Wanlisonic 160K(1 balde)
  • Dimensions:L2000*W600*H1500mm
  • Weight:Net Wt. 195KGS, Gross Wt.320KGS
  • Voltage:220V
  • Rated power:3000W
  • Frequency:50Hz-60Hz
  • Cut speed:30-90 cuts/minute
  • Blade Quantity:1pc
  • Blade materials:Titanium Alloy
  • Blade size:100-300mm(optional)
  • Cut type:sandwiches cutting
  • Maximum cutting size:12cm*12cm, height below 10cm(according to customers’ need)
  • Material of machine frame:304 Stainless Steel
  • Safety protection system:Security door
  • Certification:CE
