Ultrasonic Automatic Swiss Roll Cake Cutting Machine

This is compact slicer machine with conveyor belt, it can meet the requirements of factory and baking home for high speed continuous cutting machine, its cut speed can up to 180 cuts/minute, can cut kinds of products such as cake, bread, cookies, candy, cheese, protein bar and so on.

 Ultrasonic Automatic Swiss Roll Cake Cutting Machine

This hottest-selling ultrasonic cutting machine produced by Wanli Machinery has a small size, a small footprint, a fast cutting operation, and can reach 60-120 knives per minute at the fastest. The work efficiency is high, and the blades are imported from Germany. , Durable and competitive price.



Product data
Model
Wanlisp2-305K920L1700
Dimensions
L1270*W920*H1700mm
Weight
Net Wt. 320KGS, Gross Wt.420KGS
Voltage
220V
Rated power
8000W
Frequency
50Hz-60Hz
Cutting speed
35-60cuts/minute
Number of blades
2 (optional)
Blade materials
Titanium Alloy
Blade size
160-305mm(optional)
Cut type
Square, rectangular, cake slice, if cut triangle shape, need to lengthen the blade width
Maximum cutting size
600mmx400mm,food cutting height up to 80mm, blade up height:100mm. food height exceeds 75mm can be customized
Material of machine frame
Stainless Steel
Self cleaning
Yes or optional, need water and air compressor 7KGS
Safety protection system
Infrared inspection, frequency ultrasonic scan and fault indicator lamp
Control System
Four-axis Control System
Cutting knife control system
Servo motor
Machine mobility
Casters
Certification
CE


Ultrasonic Food Cutting Machine Advantage
• Cut to achieve contactless, zero pressure cutting processing mode.
• Treat creamy jelly and other sticky food sticky knives, smooth and beautiful.
• Fully automatic product positioning, according to the needs of all-round cutting.
• Cutting mode can be varied: circle, slice, rectangle, triangle.
• Automatic use of conveyor belts for efficient food cutting, saving manpower.
• Small size, easy handling.
• Respond to market consumers’ needs to maximize food hygiene and safety.
• Uses high frequency wave vibration to quickly process food, eliminating the traditional cutting blade continuous cleaning caused by downtime.
• Ultrasonic food cutting machine provide a new approach to cutting, slicing, and automatically turning to handle a variety of foods, making the production process, waste minimization and maintenance costs the lowest.
• Ultrasonic food cutting equipment is the use of ultrasonic energy generated 20,000 times per second high-frequency vibration between the blade and food to establish a surface almost no friction, so eliminate sticky knives and squeezing and other issues.
Product Display After Cutting





Description

The machine is an intelligent inline slicing machine with ultrasonic cutting technology, built to slice sticky, frozen, delicate and difficult products, such as cookies, ice cream roll cakes, pies, cheese, nougat, dough and other products . The cutting speed could up to 180 cuts per minute. And it allows each slice to have a clean quality cutting surface. It can not only be produced stand-alone but also be fully matched with extruder.

Average speed: about 30-180cuts per min
Friendly and easy operation
Reliable and durable ultrasonic machine
Increased quality and labor saving enhance capacity ​
Improved portion quality and consistency



Application

Ultrasonic food slicer machine is from the previous paragraph intelligent cut machine upgrade transformation, as a new generation of economical ultrasonic food processing equipment. Retains its fully automatic, multi-slice mode and high efficiency characteristics, and with the conveyor belt and external protective cover to ensure food production efficiency and process of food safety. The machine is easy to use, but also with the traditional food production line for enterprise product development and upgrading to do the facade bedding, in order to adapt to greater market consumer demand. This ultrasonic machine cuts into slices only.
It can be divided into various shapes of baked goods and frozen food, such as round, square, fan-shaped, triangular and so on. And can be customized according to customer special needs and existing conditions of the ultrasonic solution, welcome to sample test.



Exemptions
· Unless explicitly stated herein, we have made no commitment or warranty, express or implicit.
· We are not responsible for any commitment made by any third party (e.g. the dealer) other than those contained herein upon purchase of the product or any auxiliary software/hardware attached thereto. You should request any written certificate from such third party to ensure fulfillment of the said commitment.

Certificate of Warranty

The purchase invoice is the basis for our warranty and service standard, and shall be kept properly as a certificate of warranty. For fulfillment of the warranty by us or any service agency approved by us, you have to take the effective purchase invoice and the warranty card along.

Notes

· We will provide you with the warranty as specified in our service standard. For any other service which is out of the range of the warranty, you may select another service agency as approved by use for any paid service.
· You must show related certificate for provision of the warranty by a service agency approved by us.The decision on replacement of the whole machine or any component thereof shall be made by us or any service agency approved by us, and the original failed machine or any component thereof replaced shall be owned by us or the service agency.
