Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine Benefit:

1. High cutting precision, good cutting surface finish, accurate edge cutting, no deformation, no stick to the knife, fast speed, no pollution.

2. Reasonable design, simple structure, easy to use, easy to be applied to automatic production.Digital power supply, automatic frequency tracking and adjustable efficiency, can work continuously for 24 hours.

Objective:

Ultrasonic Cutting Triangle Cake Machine to solve the sticky knife problem in cutting soft and elastic food such as cake, bread, cheese, candy, chocolate, biscuit, pizza etc.An ultrasonic food cutting blades device is provided.

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic triangle bread cutting equipment. Sonic chase cutting food cutting line is transformed from a variety of customized in-line food cutting models aggregated to become the new in-line ultrasonic food cutting processing equipment. The equipment has the characteristics of assembly line operation, multiple slicing mode, longitudinal knife slitting, horizontal knife slicing or cutting, in addition to the waste rejection system to automatically remove the food edge waste from the conveyor, food production efficiency and food production quality.Ultrasonic cutting knives are made of titanium, a completely inert material approved by the food industry. Titanium has good fatigue strength, surface hardness and excellent acoustic properties.

Ultrasonic Cutting Triangle Cake Machine

Product Name Ultrasonic Cutting Cake Machine for Triangle Shapes
Model Wanlisp4-200K1200L3500
Material Titanium Alloy
Ratde Voltage 220V
Frequency 50HZ
Power 2200W
Can be controlled by touch screen Yes
Condition

New

or dicing or slicing bread and cakes.The length of the whole machine is 3.5M(divided into 2 sections). Width is 1.2M.Equipped with material rotating device.Can cut triangle, square shapes.Cutting speed 50 times/minuteThe full set of action is driven by the Servo Motor.

Application range:
Widely used in dough, marshmallows, cakes, candy and other foods of different hardness slitting, labor-saving, suitable for assembly line production, the equipment has a strip slicing and slitting mode. The working speed and angle are adjustable, easy to use single machine, can be used with the traditional food production line, so as to adapt to the market demand.

Application scope:

1、It can slice cream multi-layer cake, sandwich mousse cake, date cake, steamed sandwich cake, Napoleon, Swiss roll, brownie, tiramisu, cheese, ham sandwich and other baked goods;

2、It can slice products that need to be frozen and cut, such as cheesecake, ice cream cake, mousse cake, etc., which can be easily cut with ultrasonic blade.

3、Can slice cheese, hawthorn cake and other sticky food, such as can cheese, mozzarella, brie, etc.

Objective:

to solve the sticky knife problem in cutting soft and elastic food such as cake, bread, cheese, candy, chocolate, biscuit, pizza etc.An ultrasonic food cutting knife device is provided.

Benefit:

1. High cutting precision, good cutting surface finish, accurate edge cutting, no deformation, no stick to the knife, fast speed, no pollution.

2. Reasonable design, simple structure, easy to use, easy to be applied to automatic production.Digital power supply, automatic frequency tracking and adjustable efficiency, can work continuously for 24 hours.

What is the difference between Wanli ultrasonic cutting machine and traditional ultrasonic cutting machine?

--Ultrasonic cutting machine is a special ultrasonic equipment for cutting, is one of the important categories of ultrasonic applications.

--The principle is completely different from the traditional cutting. Ultrasonic cutting machine uses the energy of ultrasonic waves to melt the local heating of the material being cut, so as to achieve the purpose of cutting the material.

--Ultrasonic cutting machine features, does not require a sharp knife edge, does not require a lot of pressure, will not be chipped and broken on the cutting material.

--Cutting baldes in doing ultrasonic vibration, friction resistance is particularly small, the material to be cut is not easy to stick to the blade.

About machines and services?

--If you have any questions (machine installation, use method, parts replacement, maintenance, precautions, etc.) after receiving the machine or during use, please feel free to contact me, we will provide the best solution. 24 hours online service to solve any problem. Your satisfaction is our pursuit. Sincerely hope to cooperate with us.

How do I know your machine is designed for my product?

If you don't mind, you can send you a sample and we test it on the machine. During that time, we'll take clearer video and pictures for you. If there is a chance, we can take videos online for you to see.

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine

Ultrasonic Cutting Triangle Cake Machine
